Apple Display Technology Explained

Retina, Liquid Retina, Super Retina XDR, Ultra Retina XDR — and now PROLED XDR, the first touchscreen on a Mac. Apple's display names have piled up over fifteen years. Here's what each one actually means, and which differences are worth paying for.

The short version

If you only read one box, read this one:

  • "Retina" is a marketing name, not a panel type. It means the pixels are too small to pick out at a normal viewing distance. Underneath, a Retina display can be LCD, mini-LED or OLED.
  • The XDR names describe brightness and contrast, not resolution. Liquid Retina XDR is mini-LED; Super Retina XDR, Ultra Retina XDR and PROLED XDR are all OLED. XDR just means Apple's brightest, highest-contrast tier.
  • The MacBook Pro now comes with a touchscreen. The MacBook Pro with PROLED XDR Display (October 2026) uses tandem OLED, adds Touch and a Dynamic Island, and sells alongside the existing mini-LED models rather than replacing them.
  • OLED keeps spreading down the range. The iPad mini went OLED in October 2026, and Apple's first foldable, the iPhone Duo, uses OLED on both screens.
  • 120Hz is no longer a Pro-only feature. ProMotion runs on every current iPhone except the entry-level iPhone 17e, which stays at 60Hz.
  • Most of these upgrades don't change a buying decision. A refurbished MacBook Pro with a Liquid Retina XDR display is the same excellent screen it was on day one — and Apple still sells that screen new.

Below, each term in plain English — grouped so you can jump to the bit you need.

Display technology moves quickly, and Apple gives almost every step its own trademarked name. That's good for marketing and confusing for buyers. The aim of this guide is simple: strip the names back to what they physically mean, so you can tell a real difference from a rebrand.

We first published this guide in 2024 and have updated it twice since. This version folds in Apple's autumn 2026 launches — the touchscreen MacBook Pro, the OLED iPad mini, the iPhone 18 Pro and the foldable iPhone Duo — alongside the earlier changes. Anything new is flagged where it appears.

What's new in this update

The biggest Mac display change in years

Autumn 2026: Apple launched the MacBook Pro with PROLED XDR Display — tandem OLED, Touch and a Dynamic Island on a Mac for the first time (October 2026, covered in Part 08). The iPad mini moved from LCD to OLED and took the Super Retina XDR name. The iPhone 18 Pro and iPhone 18 Pro Max arrived with the same screen sizes as the 17 Pro generation, and the foldable iPhone Duo brought a 7.6-inch folding OLED. The mini-LED MacBook Pro gained an M6 14-inch model with an unchanged Liquid Retina XDR screen.

Earlier in 2026: the MacBook Pro's quantum dot film (from the M4, late 2024), the Studio Display XDR with Adaptive Sync (March 2026), and the budget MacBook Neo with a 13-inch Liquid Retina screen.

Part 01The "Retina" family: names for sharpness

Everything in this first group is about pixel density — how tightly the pixels are packed. None of these names tell you what kind of panel is underneath. They're Apple's way of saying "you can't see the individual pixels from a normal distance."

Retina

"Retina" is a trademark Apple introduced in 2010 with the iPhone 4. It refers to a display with a high enough pixel density that, at a typical viewing distance, your eye can't resolve the individual pixels. The result is text and images that look smooth rather than blocky. It's now the baseline across the MacBook Pro, MacBook Air, iPhone, iPad, Apple Watch and iMac.

The important thing to hold on to: Retina is a threshold, not a technology. A Retina screen can be an LCD, a mini-LED-backlit LCD, or an OLED. The name only promises the pixels are small enough.

Devices with Retina displays Screen size Resolution
Apple Watch 38mm 1.34 in 272×340
Apple Watch 40mm 1.55 in 324×394
Apple Watch 41mm 1.69 in 352×430
Apple Watch 44mm 1.76 in 368×448
Apple Watch 45mm 1.90 in 396×484
iPhone 4, 4S 3.5 in 960×640
iPhone 5, 5C, 5S / SE 1 4.0 in 1136×640
iPad mini 2–5 7.9 in 2048×1536
iPad 3–6 / Air 1, 2 / Pro 9.7 9.7 in 2048×1536
iPad 7, 8, 9 10.2 in 2160×1620
iPad Pro 10.5 / Air 3 10.5 in 2224×1668
iPad Pro 12.9 (1, 2) 12.9 in 2732×2048
MacBook 12-inch 12 in 2304×1440
MacBook Air 13-inch (2018–2020) 13.3 in 2560×1600
MacBook Pro 13-inch (2012–2022) 13.3 in 2560×1600
MacBook Pro 15-inch (2012–2019) 15.4 in 2880×1800
MacBook Pro 16-inch (2019) 16 in 3072×1920
iMac 24-inch (M1–M6) 24 in 4480×2520

Liquid Retina

Liquid Retina uses the same high pixel density as a standard Retina LCD. The difference is at the edges: pixel masking and anti-aliasing let Apple round the corners of the screen and shrink the bezels, so more of the front of the device is display. It's still an LCD; it just fills more of the frame.

The newest member is the MacBook Neo (March 2026), Apple's lowest-priced laptop. Its 13-inch Liquid Retina screen has no notch, but it's a step down from the MacBook Air: it covers the standard sRGB colour range rather than wide P3, and it doesn't have True Tone.

Devices with Liquid Retina displays Screen size Resolution
iPhone XR / 11 6.1 in 1792×828
iPad mini 6, 7 (A17 Pro) 8.3 in 2266×1488
iPad 10 10.9 in 2360×1620
iPad Air 11-inch (4th gen to M4) 10.9 in 2360×1640
iPad Pro 11-inch (1–4) 11 in 2388×1668
iPad Pro 12.9 (3, 4) / Air 13-inch (M2–M4) 12.9 in 2732×2048
MacBook Neo (2026) 13.0 in 2408×1506
MacBook Air 13-inch (2022–2026) 13.6 in 2560×1664
MacBook Air 15-inch (2023–2026) 15.3 in 2880×1864
What this means for you

A Liquid Retina MacBook Air is the sweet spot for most people

For everyday work — email, browsing, documents, video — a Liquid Retina LCD is genuinely all you need. You're paying a lot more for the XDR panels below, and the benefit only shows up in HDR video and bright-highlight content. If that's not your daily use, the Air's screen is the sensible choice, and it holds its value well second-hand. It's also a noticeably better screen than the new MacBook Neo's, thanks to wide P3 colour and True Tone.

Browse our refurbished MacBook Air range

Super Retina XDR

Super Retina XDR is Apple's name for its standard OLED screens. Because OLED pixels make their own light and switch off completely for true black, these displays reach very high contrast. "XDR" (Extreme Dynamic Range) is Apple's badge for its brightest, highest-contrast tier — more on that in the dynamic range section. This is the screen on every recent iPhone, including both displays on the foldable iPhone Duo.

New since our last update: the name has reached the iPad for the first time. The iPad mini with A20 Pro (October 2026) swapped its LCD for an 8.5-inch single-layer OLED. It isn't the tandem OLED used in the iPad Pro, and it runs at 60Hz rather than 120Hz.

Devices with Super Retina XDR displays Screen size Resolution
iPhone Duo — outer display 5.4 in 2034×1398
iPhone 12 mini, 13 mini 5.4 in 2340×1080
iPhone X / XS / 11 Pro 5.8 in 2436×1125
iPhone 12–14 / 12–13 Pro / 16e / 17e 6.1 in 2532×1170
iPhone 15, 16 / 14–15 Pro 6.1 in 2556×1179
iPhone 16 Pro / 17 / 17 Pro / 18 Pro 6.3 in 2622×1206
iPhone XS Max / 11 Pro Max 6.5 in 2688×1242
iPhone Air 6.5 in 2736×1260
iPhone 12–13 Pro Max / 14 Plus 6.7 in 2778×1284
iPhone 14–15 Pro Max / 15–16 Plus 6.7 in 2796×1290
iPhone 16 Pro Max / 17 Pro Max / 18 Pro Max 6.9 in 2868×1320
iPhone Duo — inner folding display 7.6 in 2670×1878
iPad mini (A20 Pro, 2026) 8.5 in 2316×1512

Ultra Retina XDR

Ultra Retina XDR debuted on the iPad Pro (M4) in May 2024. It uses Tandem OLED — two OLED light-emitting layers stacked on top of each other. Splitting the work across two layers means each one runs cooler and less hard, which lets the panel hit high, sustained brightness without the burn-in risk a single OLED layer would face. Apple pairs it with software that watches individual pixels and nudges their brightness to reduce image persistence. The same tandem approach now powers the MacBook Pro's PROLED XDR screen, below.

Devices with Ultra Retina XDR displays Screen size Resolution
iPad Pro 11-inch (M4, M5) 11.1 in 2420×1668
iPad Pro 13-inch (M4, M5) 13 in 2752×2064

Liquid Retina XDR

Liquid Retina XDR is the mini-LED MacBook Pro and 12.9-inch iPad Pro screen. It's a Liquid Retina LCD with a mini-LED backlight — thousands of tiny LEDs grouped into dimming zones behind the panel. Because the backlight can dim in zones rather than all at once, blacks look far deeper and highlights far brighter than on an ordinary LCD, without moving to OLED.

Despite the arrival of the OLED model, Apple hasn't retired this screen. The new 14-inch MacBook Pro with M6 (October 2026) keeps it unchanged, and the M5 Pro and M5 Max mini-LED models stay on sale too.

Devices with Liquid Retina XDR displays Screen size Resolution
iPad Pro 12.9-inch (5, 6) 12.9 in 2732×2048
MacBook Pro 14-inch (M1 Pro to M6) 14.2 in 3024×1964
MacBook Pro 16-inch (M1 Pro to M5 Max) 16.2 in 3456×2234

PROLED XDR — new for the MacBook Pro

PROLED XDR is Apple's newest display name, and the first to break the "Retina" naming pattern. It's the tandem OLED touchscreen on the MacBook Pro with PROLED XDR Display, announced in October 2026. Both sizes run at 254 pixels per inch. It gets its own section in Part 08.

Devices with PROLED XDR displays Screen size Resolution
MacBook Pro 14-inch with PROLED XDR (M5 Pro, M5 Max) 14.2 in 3024×1986
MacBook Pro 16-inch with PROLED XDR (M5 Pro, M5 Max) 16.3 in 3472×2266
What this means for you

The Liquid Retina XDR screen is identical on a refurbished MacBook Pro

This panel hasn't fundamentally changed since 2021 — the same mini-LED, the same 1,600-nit HDR peak, the same 1,000,000:1 contrast. Apple is still fitting it to brand-new MacBook Pros in late 2026. A refurbished 14-inch or 16-inch MacBook Pro gives you exactly the display a new mini-LED one does, for a good deal less. The PROLED XDR model is a genuine step up, but it's a separate, pricier line rather than a replacement — see Part 08 for whether it matters to you.

Browse our refurbished MacBook Pro range

This is refurbished

Part 02Resolution and pixel density

Resolution

Resolution is the pixel count of the screen, written as width × height. The MacBook Air 13-inch M2, for example, is 2560×1664 — 2,560 pixels across, 1,664 down. More pixels on the same-size screen means you can fit more on screen at once and everything looks sharper, though at native settings it also looks slightly smaller. That trade-off is why a higher-resolution screen suits spreadsheets, timelines and multi-track work: more fits without scrolling.

Resolution on its own doesn't tell you sharpness, though — a big screen and a small screen can share a resolution. What matters is pixel density, measured in pixels per inch (PPI). That's the number behind the "Retina" claim, and it's why a 6-inch phone and a 16-inch laptop with similar resolutions look equally crisp at their own viewing distances. The PROLED XDR MacBook Pro, for instance, has slightly more pixels than the mini-LED model mostly because its screen is slightly taller, not because it's sharper.

This is refurbished

Part 03Refresh rate: ProMotion, Adaptive Sync and LTPO

Refresh rate is how many times per second the screen redraws its image, measured in hertz (Hz). Higher is smoother — scrolling and animation look more fluid. But running a screen fast all the time wastes power, so the clever part is varying the rate to match what's on screen.

ProMotion

ProMotion is Apple's name for a display that varies its own refresh rate, up to 120Hz. Introduced on the iPad Pro in 2017 and later added to the MacBook Pro and iPhone, it speeds up to 120Hz for scrolling and gaming, then drops right down — as low as 10Hz or below — when the image is static, to save power. You get smoothness when it helps and efficiency when it doesn't. The PROLED XDR MacBook Pro runs from 10Hz to 120Hz, and adds fixed rates such as 48Hz and 50Hz for film and video work.

With the iPhone 17 generation (September 2025), ProMotion reached the standard iPhone for the first time, and it's on the iPhone Air, iPhone 18 Pro and both screens of the iPhone Duo. The exception is the entry-level iPhone 17e (March 2026), which stays at 60Hz. Note too that the new OLED iPad mini runs at 60Hz — OLED doesn't automatically mean ProMotion.

LTPO — the technology under ProMotion

ProMotion is the feature; LTPO (low-temperature polycrystalline oxide) is the panel technology that makes it possible. LTPO is a type of backplane — the layer that controls each pixel — efficient enough to let the display slow its refresh rate right down without flicker. It's also what enables the Always-On display, where the clock and widgets stay faintly visible because the screen can idle at around 1Hz.

Adaptive Sync — for external displays

Adaptive Sync is Apple's refresh-rate term for external monitors rather than built-in screens. It arrived with the Studio Display XDR in March 2026. Where ProMotion targets efficiency on a laptop or phone, Adaptive Sync matches the display's refresh rate to whatever the Mac is sending — a continuously variable range from 47Hz to 120Hz. In practice that means smoother video playback and lower-latency gaming, with the picture and the source kept in step so motion looks clean.

What this means for you

120Hz is worth having, but you rarely need to chase the newest model for it

ProMotion makes day-to-day use feel noticeably smoother, and it's on every MacBook Pro since 2021 and every iPhone 17 and 18 model except the 17e. If a fluid screen matters to you, a refurbished 14-inch or 16-inch MacBook Pro already has it. Adaptive Sync is specific to the Studio Display XDR — not something built-in Mac screens gain or lose.

Browse our refurbished MacBook Pro range

This is refurbished

Part 04Colour: gamut, depth and quantum dot

Wide Colour (P3)

Colour gamut is the range of colours a screen can show. Wide Colour (P3) covers a noticeably larger range than the older sRGB standard — roughly 25% more colours — with deeper reds and greens in particular. It's the standard across nearly all of Apple's displays and the working reference for most photographers and video editors. The one current exception is the MacBook Neo, which sticks to sRGB.

Adobe RGB — now on a laptop too

Adobe RGB is the colour space print and design professionals often work in. Apple first added it alongside P3 on the Studio Display XDR (March 2026), and the PROLED XDR MacBook Pro is the first portable Mac to support both — with wider coverage in greens and cyans, and more than 80% of the even larger Rec. 2020 range used for HDR grading. Both spaces sit in a single default preset. For most people, P3 is already more colour than their eyes or their content will use.

1 billion colours (10-bit depth)

Colour depth is how many shades of each colour a screen can show. Older 8-bit displays produce about 16.8 million colours. XDR displays use 10-bit depth — 1,024 shades per primary colour, which combine to roughly 1.07 billion. The practical benefit is smoother gradients, with less visible "banding" in skies and subtle shading.

Quantum dot — the mini-LED MacBook Pro's quiet upgrade

Starting with the M4 MacBook Pro in late 2024, Apple quietly switched the film inside the Liquid Retina XDR panel from a red KSF phosphor film to a quantum dot film — without announcing it.

Both films do the same job — they help the mini-LED backlight produce a wider range of colours than it otherwise could. Quantum dots are tiny semiconductor particles that emit very precise, pure wavelengths of light when energised, which gives slightly better colour accuracy and faster pixel response (so motion looks a touch cleaner). Apple had previously stuck with KSF because early quantum dot films used cadmium and were less efficient; newer cadmium-free films closed that gap, so Apple made the switch.

It's honestly a small change — most people wouldn't spot the difference side by side — which is why it stayed off the spec sheet. It also only applies to the mini-LED models. The PROLED XDR MacBook Pro has no backlight to filter: each OLED pixel makes its own light.

This is refurbished

Part 05Brightness, contrast and dynamic range

Brightness (nits)

Brightness is measured in nits (one nit is roughly the light of one candle per square metre). Higher nits mean a screen you can read in brighter surroundings. The right number depends on where you work: a lower brightness is easier on the eye in a dim room, while bright offices or outdoor use benefit from a higher-nit display.

For reference, mini-LED MacBook Pro screens reach 1,000 nits full-screen and 1,600 nits peak — but that peak is for HDR content only. The PROLED XDR model also holds 1,000 nits full-screen, then peaks at 2,000 nits for both HDR and everyday SDR content, which is what makes the biggest difference outdoors.

Contrast ratio

Contrast ratio is the gap between the brightest white and the darkest black a screen can show, written like 1,000,000:1. A higher ratio means deeper blacks and more separation between tones. The Liquid Retina XDR MacBook Pro displays are rated at 1,000,000:1. Because OLED pixels switch fully off, the PROLED XDR display is rated ten times higher, at 10,000,000:1.

Dynamic range: SDR, HDR and XDR

Dynamic range ties brightness and contrast together — it's the span from the darkest detail to the brightest highlight a screen can display at once.

Term What it means
SDR Standard Dynamic Range. The baseline — 8-bit colour, limited brightness and contrast, typically 100–300 nits. Fine indoors, but detail can wash out or get lost in very bright or very dark scenes.
HDR High Dynamic Range. A wider brightness and contrast range, usually peaking above 1,000 nits, so bright highlights and dark shadows both keep their detail. A clearer, more lifelike image.
XDR Extreme Dynamic Range. Apple's own top tier, built on HDR — up to 1,600 nits peak on mini-LED Macs, 2,000 nits on the PROLED XDR MacBook Pro and Studio Display XDR, contrast from 1,000,000:1 up to 10,000,000:1, P3 wide colour and 10-bit depth.
This is refurbished

Part 06Panel technology: LCD, mini-LED and OLED

This is what's physically behind the marketing names. There are really three families, plus a couple of variations.

LED-backlit LCD

A standard LCD (liquid crystal display) can't make its own light — it uses a layer of LEDs behind the panel as a backlight. The liquid crystals then let that light through, pixel by pixel, to form the image. This is the technology in most iPhones before OLED, most iPads, the MacBook Air, the MacBook Neo and the iMac.

Mini-LED

Mini-LED is an LCD backlight made of much smaller LEDs — around 100 microns versus 200-plus for standard LEDs. Because they're smaller, you can fit far more of them and group them into hundreds or thousands of independently controlled dimming zones. That gives much better contrast and brightness than a normal LCD, which is how Apple builds the "XDR" experience without OLED. It's the backlight in the mini-LED MacBook Pro and 12.9-inch iPad Pro. The Studio Display XDR pushes this furthest, with over 2,300 dimming zones.

Devices with mini-LED displays Screen size Resolution
iPad Pro 12.9-inch (5, 6) 12.9 in 2732×2048
MacBook Pro 14-inch (M1 Pro to M6) 14.2 in 3024×1964
MacBook Pro 16-inch (M1 Pro to M5 Max) 16.2 in 3456×2234
Studio Display XDR (2026) 27 in 5120×2880

OLED

OLED (organic light-emitting diode) is the alternative to a backlit LCD. Each pixel makes its own light and can switch off entirely, so blacks are perfectly black and contrast is effectively unlimited. It's on every recent iPhone, the Apple Watch, and — since October 2026 — the iPad mini and the PROLED XDR MacBook Pro. The trade-offs are cost and, historically, burn-in risk — which is what Tandem OLED (below) is designed to reduce.

Tandem OLED

Tandem OLED stacks two OLED layers to share the workload, reaching higher sustained brightness with less strain on each layer. Apple uses it in the iPad Pro (M4 and M5) — the "Ultra Retina XDR" screen — and now in the MacBook Pro with PROLED XDR Display, where Apple says it has also reworked the layers to keep brightness uniform and cut the internal reflections common in OLED panels.

IPS and Oxide TFT

Two supporting terms you'll see in spec sheets. IPS (in-plane switching) is the LCD panel type Apple uses for wide viewing angles and consistent colour — the image stays accurate when you look from the side, unlike older panel types. Oxide TFT refers to the transistors that switch each pixel: using an oxide material instead of silicon lets pixels charge faster and pass more light, so the screen is brighter and more responsive while using less power.

This is refurbished

Part 07Finish, coatings and comfort features

Standard vs Nano-texture glass

When you buy certain Apple displays you can choose standard glass or nano-texture glass. Both have an anti-reflective coating; nano-texture goes further with an etched matte finish that scatters reflections, for people working near windows or under bright lights. It's an option — not every device offers it — and it typically costs extra.

Nano-texture is available on the iMac 24-inch (M4, M6), iPad Pro (M4/M5), MacBook Pro (M4 onwards, including the M6 model), the Studio Display and Studio Display XDR, and the older iMac 27-inch and Pro Display XDR. New in autumn 2026: it's an option on the PROLED XDR MacBook Pro, where it's now etched directly into the cover glass; on the 256GB and 512GB iPad mini (A20 Pro); and it comes as standard on the iPhone Duo's inner folding screen.

Oleophobic and anti-reflective coatings

An oleophobic coating repels the oils from your fingers, so fingerprints, dust and smudges wipe off more easily. An anti-reflective coating cuts the light bouncing back off the glass, so what's on screen stays visible and glare is reduced. Both are standard on Apple's displays — and with a touchscreen Mac now on sale, the oleophobic coating matters on a laptop for the first time.

True Tone

True Tone, introduced in 2016, uses ambient light sensors to adjust the screen's colour temperature to match the light in the room. The screen looks more natural and paper-like as you move between warm and cool lighting. It can be turned off, which some people prefer for colour-critical work. The MacBook Neo is one of the few current Apple screens without it.

Night Shift

Night Shift shifts the display towards warmer tones in the evening, cutting blue light to reduce eye strain and help with sleep. It's a scheduling feature rather than a hardware one, and works across Apple's devices.

This is refurbished

Part 08Touch comes to the Mac: the PROLED XDR display

For years Apple said a touchscreen didn't belong on a Mac. On 28 October 2026 it changed its mind. The MacBook Pro with PROLED XDR Display comes in 14-inch and 16-inch sizes with M5 Pro or M5 Max chips, and goes on sale on 6 November 2026. It's the first Mac with a touchscreen, the first with an OLED display, and the first with a Dynamic Island in place of the notch.

It's a new line, not a replacement. Apple now sells two kinds of MacBook Pro side by side: the familiar mini-LED model (with M6, M5 Pro or M5 Max) and this OLED touch model (M5 Pro or M5 Max only). The chips are the same; the screen is the difference you're paying for.

The panel: tandem OLED

PROLED XDR uses the same two-layer tandem OLED idea as the iPad Pro, tuned for a laptop. Apple's headline numbers: up to 2,000 nits peak in both SDR and HDR, 1,000 nits sustained full-screen, a 10,000,000:1 contrast ratio, ProMotion from 10Hz to 120Hz, and P3 plus Adobe RGB colour. Every panel is factory calibrated, and the display engine in the M5 Pro and M5 Max adjusts each pixel in real time for content, temperature and how much that pixel has been used — Apple's answer to OLED's long-term wear concerns. Because OLED has no blooming, you don't get the faint halos mini-LED can show around bright objects on black backgrounds.

The touch layer

The touch sensor is built into the display panel itself rather than laid on top, which Apple says cuts latency so it feels like you're touching the content directly. The basics are what you'd expect: swipe to scroll, pinch to zoom, drag and drop between apps, double-tap a window to fill the screen, or flick it to tile into place. Touch works alongside the keyboard and trackpad rather than replacing them.

Two practical details worth knowing. Apple redesigned the hinge so the screen doesn't wobble when you tap it. And existing apps work with touch from day one, because macOS translates a tap into a click — though apps built specifically for touch (Apple's own Final Cut Pro, Logic Pro and Pixelmator Pro, plus third-party tools like Lightroom, DaVinci Resolve and Blender) will make better use of it.

The Dynamic Island

The notch is gone. In its place is a Dynamic Island, the same idea as on iPhone: a pill-shaped area at the top of the screen that expands to show Spotlight, Siri, live updates and controls like music playback and incoming calls — and, because the screen is touch-sensitive, you can tap it directly.

Pro features

This is pitched as a portable reference display. It includes Apple's display calibrator and industry-standard reference modes for film, photography and print; DICOM modes for viewing medical images (for research and teaching, not diagnosis); genlock, which syncs the screen's refresh to a film camera to avoid flicker and tearing on set; and colour matching with the iPhone 18 Pro and Studio Display XDR.

The new display also made the machine slimmer and lighter: Apple quotes the 14-inch at 3 pounds and the 16-inch at 4 pounds, and slimmer borders take the 16-inch screen from 16.2 to 16.3 inches.

Liquid Retina XDR (mini-LED) PROLED XDR (tandem OLED)
Panel LCD with mini-LED backlight and quantum dot film Two stacked self-lit OLED layers
Sizes 14.2 in / 16.2 in 14.2 in / 16.3 in
Resolution 3024×1964 / 3456×2234 3024×1986 / 3472×2266
Brightness 1,000 nits sustained; 1,600 nits peak (HDR only) 1,000 nits sustained; 2,000 nits peak (SDR and HDR)
Contrast 1,000,000:1 10,000,000:1
Colour P3 P3 + Adobe RGB, 80%+ Rec. 2020
Refresh ProMotion, up to 120Hz ProMotion, 10–120Hz
Touch No Yes
Top of screen Notch Dynamic Island
Chips M1 Pro to M6 (current: M6, M5 Pro, M5 Max) M5 Pro, M5 Max
What this means for you

A brilliant screen — but only some people need it

On paper, PROLED XDR is the best laptop screen Apple has made. It starts at £2,899 for the 14-inch M5 Pro, a clear premium over the mini-LED MacBook Pro with the same chip, so the question is whether you'll use what the extra money buys. If you grade HDR video, prepare work for print in Adobe RGB, work outdoors a lot, or want to draw and play instruments directly on screen, it's a real step forward.

If you mainly want MacBook Pro performance, the PROLED model is no faster — it uses the same M5 Pro and M5 Max chips as the mini-LED line. Touch on a laptop is also brand new, and app support will take time to mature. It will be a while before these models reach the refurbished market, and in the meantime a refurbished mini-LED MacBook Pro remains the better-value way to get a pro-grade Mac screen.

Browse our refurbished MacBook Pro range

This is refurbished

Part 09The 2026 external displays: Studio Display and Studio Display XDR

Apple refreshed its external monitor line in March 2026, introducing two of the terms above and retiring an old product name.

Display Panel & refresh Who it's for
Studio Display (2026) 27-inch 5K LCD, 600 nits, 60Hz, P3 wide colour, True Tone Everyday and creative work; the sensible all-rounder that pairs with any modern Mac.
Studio Display XDR (2026) 27-inch 5K mini-LED, 2,000+ dimming zones, up to 2,000 nits peak HDR, 120Hz with Adaptive Sync, P3 + Adobe RGB HDR video, 3D and print pros. Replaces the Pro Display XDR in the line-up.

The headline is that the Studio Display XDR brings the MacBook Pro's mini-LED approach to a desktop monitor, adds Adaptive Sync, and supports both P3 and Adobe RGB. The older Pro Display XDR name has been retired. The standard Studio Display, meanwhile, stays a 60Hz LCD — a reminder that "Studio Display" and "Studio Display XDR" are quite different screens despite the shared name.

The names describe the experience Apple wants to sell. The panel underneath is what you're actually paying for.
This is refurbished

Glossary of terms

Adaptive Sync
A variable refresh rate for external displays that matches the monitor to the source, 47–120Hz. New on the Studio Display XDR (2026).
Adobe RGB
A colour gamut common in print and design work. Supported alongside P3 on the Studio Display XDR and the PROLED XDR MacBook Pro.
Always-On
A display mode that keeps the lock screen faintly visible by idling at a very low refresh rate. Enabled by LTPO.
Colour depth
How many shades of each colour a screen shows. 8-bit is ~16.8m colours; 10-bit is ~1.07 billion, for smoother gradients.
Colour gamut
The overall range of colours a display can reproduce, e.g. sRGB, P3, Adobe RGB, Rec. 2020.
Contrast ratio
The difference between the brightest white and darkest black, e.g. 1,000,000:1. Higher means deeper blacks.
Dynamic Island
The pill-shaped, interactive area at the top of the screen that shows alerts, live updates and controls. On iPhone since the 14 Pro, and on the Mac since the PROLED XDR MacBook Pro.
Genlock
Syncing a display's refresh rate to a camera's capture rate, to avoid flicker and tearing when filming a screen. Supported on the PROLED XDR MacBook Pro.
HDR High Dynamic Range
A wide brightness-and-contrast range, typically peaking above 1,000 nits, so highlights and shadows both keep detail.
IPS In-plane switching
An LCD panel type giving wide viewing angles and consistent colour off-axis.
KSF phosphor
The red-boosting film Apple used inside mini-LED MacBook Pro displays before switching to quantum dot in late 2024.
LCD Liquid crystal display
A display that shapes light from a separate LED backlight; it can't make its own light.
LTPO Low-temperature polycrystalline oxide
The efficient backplane technology that lets a screen drop its refresh rate right down — the tech behind ProMotion and Always-On.
Mini-LED
An LCD backlight of very small LEDs grouped into many dimming zones, for much better contrast than standard LCD.
Nano-texture
An etched matte glass option that scatters reflections for use in bright environments.
Nit
The unit of screen brightness (one candela per square metre). Higher nits = brighter display.
OLED Organic light-emitting diode
A display where each pixel makes its own light and can switch fully off, for perfect blacks and high contrast. On iPhone, Apple Watch, iPad Pro, iPad mini and the PROLED XDR MacBook Pro.
P3 Wide colour (Display P3)
Apple's standard wide colour gamut, ~25% more colours than sRGB.
PROLED XDR
Apple's name for the tandem OLED touchscreen on the MacBook Pro with PROLED XDR Display (October 2026). Up to 2,000 nits, 10,000,000:1 contrast, P3 and Adobe RGB.
ProMotion
Apple's variable refresh rate up to 120Hz, on MacBook Pro, iPad Pro and every iPhone 17 and 18 model except the 17e.
Quantum dot
A colour film of light-emitting semiconductor particles. Replaced KSF phosphor in the mini-LED MacBook Pro from the M4 (2024) for better colour and motion.
Rec. 2020
A very wide colour gamut used as the target for HDR video. The PROLED XDR display covers more than 80% of it.
Refresh rate
How many times per second the screen redraws, in Hz. Higher is smoother.
Resolution
The pixel count of a screen, width × height.
Retina
Apple's name for a display dense enough that pixels aren't visible at normal distance. A threshold, not a panel type.
SDR Standard Dynamic Range
The baseline brightness-and-contrast range, ~100–300 nits, 8-bit colour.
Tandem OLED
Two stacked OLED layers for higher sustained brightness and lower burn-in risk. Used in the iPad Pro (Ultra Retina XDR) and the MacBook Pro (PROLED XDR).
TFT / Oxide TFT Thin-film transistor
The transistors that switch each pixel. Oxide versions charge faster and pass more light for a brighter, more efficient screen.
Touch on Mac
Touchscreen input, built into the panel, on the PROLED XDR MacBook Pro. The first Mac to support it.
True Tone
Adjusts the screen's colour temperature to match ambient lighting for a more natural look.
XDR Extreme Dynamic Range
Apple's top display tier, built on HDR: up to 1,600 nits peak on mini-LED Macs (2,000 on PROLED XDR and Studio Display XDR), 1,000,000:1 to 10,000,000:1 contrast, P3, 10-bit.
